| Place of Origin: | CHINA |
| Brand Name: | master |
| Model Number: | A4 A3 |
| Minimum Order Quantity: | 100 pcs |
|---|---|
| Packaging Details: | STANDARD EXPORT PACKING |
| Delivery Time: | W'IN 20 DAYS AFER RECEIVED YOUR DEPOSIT |
| Payment Terms: | TT |
| Supply Ability: | 50000PCS/MONTH |
| Materials: | Metal | Size: | A4 A3 |
|---|---|---|---|
| Laminating Thickness: | 1MM | Speed: | 650mm/min |
| Rollers: | 4 |
A4 FGK230,A3 FGK 320 The diemater of roller is 25MM.
1. Cover material: metal
2. Max. laminating width: 230/320mm
3. Min. laminating speed: 650mm/min
4. Max. laminating thickness: 1mm(1000MIC)
5. Number of rollers: 4 rollers(two hot,two cold)
6. Power: AC 110V, 220V/50Hz, 60Hz
7. Consumption: 500/560W
8.Operating temperature: 100 - 180°C
9. N.G.Weight: 26/28kgs/4PCS/CTN,N.W.:16/17KGS/2PC/CTN
10. Dimensions: 48/55.5 x 27x 33.5cm
11. Warming-up time: 3-4min
packing:A4 4pcs/ctn,A3 2pcs/ctn
| Laminating width | A3 320MM/12.6 INCHES |
| Laminating thickness | 1 MM |
| Speed | 560mm/min |
| Preheat time | 3-4 min |
| rollers | 4 |
| Diameter for the rollers | 25mm/22mm |
| Display | no meter/with meter |
| Lami Temperature | 80-180℃ |
| Power | 560w |
| Reverse | yes |
| Cold laminating fuction | yes |
| Machine size | 55x21x11cm |
| QTY/CTN | 4 |
| MEANS | 55x27x61cm |
| G.W./N.W. | 32kgs/30kgs |
we also supply Master laminating pouch film
